Sheet Offset
Ryobi, 520, 1996 (Ref.:M5750)
Year: 1996   Size: 36 x 52 cm
Price: on request
conventional dampening
Heidelberg, GTO 52+, 1994 (Ref.:M5769)
Year: 1994   Size: 360 x 520 mm   Impression: 46 Mio.
Price: on request
Varn Kompac dampening
Plusversion
With NP unit, Numbering and perforating unit
Adast, DOMINANT 515, 1991 (Ref.:M5835)
Year: 1991   Size: 380 x 520 mm
Price: on request
standart machine
Heidelberg, KOR, 1964 (Ref.:M5853)
Year: 1964   Size: 400 x 570 mm
Price: on request
Heidelberg, Speedmaster SM 52-2, 1997 (Ref.:M5693)
Year: 1997   Size: 370 x 520 mm   Impression: 32 Mio.
Price: on request
Alcolor dampening system
Dampening solution circulation and cooling: M.G.E. ECO
Blanket washup device
Inking unit with program-controlled washup device
Side lay control
Sheet decurler
Mediprint powder sprayer
Eltex antistatic device
Plus version
Plate punch
Ryobi, 3300 CR, 1995 (Ref.:M5748)
Year: 1995   Size: 340 x 460 mm
Price: on request
Straight machine
Heidelberg, GTOZP 46, 1978 (Ref.:M5767)
Year: 1978   Size: 320 x 460 mm   Impression: 96 mio
Price: on request
Perfection
Heidelberg, Printmaster PM 52-2, 2005 (Ref.:M5866)
Year: 2005   Size: 370mm x 520mm   Impression: 40 mio
Price: on request
presscontrol with remotely adjustable circumferential and lateral register
Heidelberg suction tape feeder
ultrasonic and electromechanical double-sheet detectors
sheet arrival control
remotely controllable front and pull lays
alcolor continuous-film dampening system with circulation, cooling and alcohol stabilization
18 rollers, including 4 form rollers
laser-slit blade-type ink fountain
chromed plate cylinder
easyplate with automatic positioning run
diagonal register adjustment via plate c
manual adjustment of cylinder contact pr
corrosion-proof blanket cylinder (3mm in undercut)
anodized impression cylinder with replac
bearer-on-bearing running
Heidelberg, Speedmaster SM 52-2, 2008 (Ref.:M5879)
Year: 2008   Size: 370 x 520 mm   Impression: 39 Mio.
Price: on request
N+P Numbering and perforatin unit
Type of dampening system: Alcolor
Type of clamping: AutoPlate
Baldwin HydroStar Dampening solution circulating and cooling device
Alphatronic 200 powder spray devices
CPC, control system integrated register
Press speed: 13.000
Crowned water pan roller
With program-controlled washup device
With form roller cross bars
With ink flow control
With pull lay control
With double sheet detector - pulling device
With interface adapter
Sheet slow-down device: Suction tape 9 m
Heidelberg, GTOZ 52, 1992 (Ref.:M5887)
Year: 1992   Size: 360 x 520 mm
Price: on request
Alcolor
BALDWIN
cleaned and checked
good condition without any damage
plus version
Heidelberg, Printmaster PM 52-2, 2006 (Ref.:M5890)
Year: 2006   Size: 370mm x 520mm   Impression: 20 Mio
Price: on request
alphatronic 200 powder unit
AutoPlate
blanket cylinders chromed
CPC Classic
double sheet control
flat pile delivery
IPA- Technotrans
Plate Cylinder Chrome
RSP Inline Finishing System
Stream Feeder
Ultrasonics double sheet controll
washing device
Hans Gronhi, GH 524, 2008 (Ref.:M5740)
Year: 2008   Size: 360 x 520 mm   Impression: 15 mio.
Price: on request
Antistatic blower on feeder head
Side guided paper detector
Oscillating Ink Form Rollers
Shinmatic continuous dampening
Operation Console
Automatic Blanket Wash-up System
Semi-automatic Plate Changer
Automatic Ink Roller Cleaning System
Roland, R 204 E OB, 2004 (Ref.:M5766)
Year: 2004   Size: 520 x 740 mm   Impression: 124 Mio.
Price: on request
Autoplate: semi-automatic plate change system
cardboard attachment
cocking register
RCI remote control inking
Rolandmatic
Sakurai, 472 EDII, 1999 (Ref.:M5808)
Year: 1999   Size: 520 x 720 mm   Impression: 51 Mio.
Price: on request
SCCII control desk
SPC semi automatic plate change
SAS, Sakurai auto Set (preset)
Automatic washers of blanket
Olivermatic, continuous dampening system
IR Dryer
High pile delivery
Komori, LITHRONE L-428, 1997 (Ref.:M5839)
Year: 1997   Size: 520 x 720 mm   Impression: 38 Mio.
Price: on request
Speed: 15.000 sheet/h
Max paper size: 520 x 720 mm
Min paper size: 230 x 305 mm
Thickness: 0,04-0,8 mm
Print area size: 510 x 710 mm
Plate size: 600 x 730 mm thickness: 0,30 mm
Blancket size: 670 x 740 mm thickness: 1,90 mm
Dimensions: L. 7,00 mt. x W. 3,20 mt. x H. 2,50 mt.
Power requirement: Kw 29 approx.
Weight: 14.000 Kg. approx.
Heidelberg, Speedmaster SM 102-4-P3, 1999 (Ref.:M5841)
Year: 1999   Size: 700 x 1020 mm   Impression: 265 Mio.
Price: on request
alcolor continous dampening
CP 2000
autoplate
Technotrans cooling
Grafix powerder unit
ink roller washing device
blanket washing device
Heidelberg, MOVP-S, 1987 (Ref.:M5885)
Year: 1987   Size: 480 x 650 mm
Price: on request
alcolor, Baldwin
Bacher register
CPC 1.01
low pile delivery
perfecting 4/0 - 2/2
plate punch
Plus Version
Quick action clamps
Komori, Spica 429, 2007 (Ref.:M5886)
Year: 2007   Size: 530 x 750 mm
Price: on request
Automatic Plate Loading
Automatic wash up systems
Grafix Megatronic powdering device
Online – Anbindung PDM Color Management
PDC-Lite Print density Control-Spectrophotometer
Standard light lamp
Straight machine
TECHNOTRANS alpha d cooling and circulation device
Touch Screen panel
traversing rollers
Ultrasonics double sheet controll
KBA, RAPIDA 104-5 CX + L, 1997 (Ref.:M5212)
Year: 1997   Size: 720 x 1050   Impression: 90 mio
Price: on request
Non stop Feeder
Non stop feeder
IR dryer
Colortronic ink remote control
electr. double sheet control
Auto blanket wash
automatic inkroller wash-up device
automatic plate change
Heidelberg, Printmaster PM 52-5 P, 2008 (Ref.:M5827)
Year: 2008   Size: 370 x 520 mm   Impression: 22 Mio.
Price: on request
presscontrol with remotely adjustable circumferential and lateral register
Heidelberg suction tape feeder
ultrasonic and electromechanical double-sheet detectors
sheet arrival control
remotely controllable front and pull lays
alcolor continuous-film dampening system with circulation, cooling and alcohol stabilization
chromed plate cylinder
easyplate with automatic positioning run
diagonal register adjustment via plate clamping bar
manual adjustment of cylinder contact pressure (on operator´s side)
max. sheet size 370mm x 520mm
min. sheet size in straight printing 105mm x 145mm
min. sheet site in perfecting printing 1
max. printing size in straight printing
KBA, Rapida 105-5+L SW2PWHA, 2000 (Ref.:M5823)
Year: 2000   Size: 720 x 1050 mm   Impression: 81 Mio.
Price: on request
Stream vacuum feeder
Varidamp dampening system
PWHA semi-automatic plate change
Colortronic console
Ergotronic remote console for ink, dampening and register control
Perfector after 2. Unit (was running as straight )
Automatic washing devices (rollers, cylinders, blanket)
Powder sprayer
Nonstop delivery
IR dryer
Compressor
Punch and bender
Max. sheet size: 720 x 1050 mm
Min. sheet size: 360 x 520 mm
Max printing area: 710 x 1040 mm
Heidelberg, Speedmaster CD 74-5-P-C, 2008 (Ref.:M5824)
Year: 2008   Size: 530 x 740mm   Impression: 178 mio.
Price: on request
prinect CP2000 with color control system
Preset feeder
alcolor vario continuous-film dampening system
hydrostar central dampening solution supply
Programm-controlled inking roller wash-up device
autoplate
Programm-controlled blanket washup device
airtransfer, air-supported sheet guidance between the printing units
preset high-pile delivery with slide-in dryer option
airstar central air supply cabinet
width 3,31m
width of press and peripherals 4,06m
width of press and peripherals with open
height (without inkLine) 1,94m
Roland, R 305 P, 1997 (Ref.:M5830)
Year: 1997   Size: 530 x 740 mm   Impression: 197 Mio.
Price: on request
Auto Blanket and Ink Wash
RCI remote control inking
Rolandmatic Delta dampening
electronical double sheet control
photo-electronical sidelay control
electronical sidelay control
electronical sidelay control with acoustic warning signal
wash device for impression cylinders
ink-roller wash device
remote register adjustment
suction tape feed board
nonstop delivery manuel
Standard equipped machine
impression, balanket, plate cylinders c
Automatich formatregister
KBA, Rapida 74-5, 2003 (Ref.:M5842)
Year: 2003   Size: 520 x 740 mm   Impression: 70 Mio.
Price: on request
Automatic ink roller wash-up device
Blanket wash-up device
CIP3
Impression cylinder washer
IR-dryer
SAPC
Temperatuer control
Roland, R 705 DD, 2012 (Ref.:M5878)
Year: 2012   Size: 740 x 1040 mm   Impression: 199 Mio.
Price: on request
Sheet size max: 40 x 1040 mm
Sheet size min: 340 x 480 mm
Print area max: 715 x 1020 mm
Printing plate format: 785 x 1030 mm
Printing plate thickness: 0.28 mm
Substrate thicknesses: 0.04 - 1.0 mm
Stack height including pallet, feeder: 1320 mm
Stack weight maximum feeder: 2200 kg
Stack height including pallet, boom: 1225 mm
Stack weight maximum boom: 2070 kg
Machine speed: 16,000 Bg / h
Direct Drive:
Simultaneous plate change in all printing units (printing units can also be selected individually)
Simultaneous plate change with blanket w
washing is optional)
Heidelberg, Speedmaster SM CD 102 S+L, 1992 (Ref.:M5849)
Year: 1992   Size: 720 x 1020 mm   Impression: 241 Mio.
Price: on request
The 1. and 2. units are not working at this moment, because there are some parts missing. The
missing parts are Clamping strip of plate cylinder, various roller holders and the rubber rollers.
The other 4 Printing units and Coating unit are working and the machine is still in production.
Technical data:
Number of printing unit 6
Number of coating unit 1
Prinect CP2000 Center
Min. sheet size 340 x 480 mm
Max. sheet size 720 x 1020 mm
Preset feeder 1230 mm
Preset delivery 1205mm
Speed max. 15.000 sheets/hour
